Large-Format 3M Type C Radial Finishing in a Configurable Loose-Disc Format
3M Scotch-Brite 6″ Type C radial bristle discs provide flexible, controlled contact for cleaning, deburring, blending and refining larger components. Their thin, curved bristles follow contours, radiused edges, profiles and irregular surfaces with less manipulation than a firmer Type A construction.
Ceramic alumina abrasive is distributed throughout the moulded bristles, allowing fresh abrasive to become exposed as the tips wear. This supports consistent cutting and finishing without requiring a separate polishing compound.
Each disc is supplied individually for replacing worn leaves or building a supported working wheel. Use six to eight matching discs with the compatible large radial disc flange and adapter system.
Why Choose Type C Bristles?
Flexible Contour Conformity
The thin, curved Type C bristles flex around contours, radiused edges, profiles and irregular components. This helps maintain controlled surface contact as the workpiece geometry changes.
Genuine 3M BB-ZB Construction
These are genuine 3M Scotch-Brite BB-ZB radial bristle discs. Ceramic alumina abrasive is distributed throughout the moulded bristles, exposing fresh abrasive as the bristle tips gradually wear.
Controlled, Compound-Free Finishing
The open moulded-bristle construction provides controlled cleaning, deburring and surface refinement without loose wire filaments. It also helps manage loading and localised heat when used with light pressure, without requiring a separate polishing compound.
Type C or Type A: Which Bristle Type Should You Choose?
Type C bristles provide flexible contact around contours, profiles and irregular components. Where firmer contact and more aggressive cutting are required across flatter or more accessible surfaces, compare the Dedeco TA/Type A range.
Typical Applications
- Removing rust, oxidation, weld discolouration and surface contamination from suitable metal surfaces
- Controlled deburring and edge refinement on contoured, profiled and machined components
- Blending tool marks, scratch patterns and transition lines while maintaining contact around changing geometry
- Cleaning and finishing castings, fabricated parts and larger components
- Producing controlled satin, blended and refined surface finishes without a separate polishing compound
- Preparing suitable surfaces for coating, polishing or subsequent finishing stages
- Building a supported working wheel of six to eight matching loose discs for broader surface coverage
Suitable Materials
These 3M Type C discs are suitable for use across metals including carbon steel, stainless steel, cast iron, aluminium, brass, copper and bronze. They can also be used for suitable wood, composite and plastic applications where their flexible, compound-free finishing action is appropriate.
Always test the selected grade on an inconspicuous area first, particularly on softer, coated, plated or heat-sensitive materials. Begin with the finest grade capable of producing the required result.
Loose-Disc Supply Format
Individual Loose Disc
Each variation is one individual 6″ 3M Type C disc with a 2″ centre hole. This format is intended for replacing worn leaves or building a working wheel with the separately available flange and adapter system.
- Supplied as one genuine 3M Scotch-Brite loose disc
- Choose six to eight matching discs of the same grade
- Compatible flange and adapter system required
- Mounting components are not included
Loose discs must not be mounted individually or directly onto an unsupported shaft, spindle or pigtail.
Building a Supported Working Wheel
The separate flange supports both sides of the disc stack and creates a stable central hub. The adapter is then selected to match the machine mounting.
- Use the telescopic adapter for compatible parallel shafts
- Use the tapered-spindle adapter for suitable polishing pigtails and tapers
- Keep every disc aligned in the same direction of rotation
- Do not combine different grades or bristle constructions in one working wheel
The number of discs selected determines the working width. Six to eight discs provides a supported production wheel while retaining the flexibility of the Type C bristles.
Grades & Selection
| Colour | Grade | Typical Use |
|---|---|---|
| Brown (Ultra-Coarse) |
36 Grit (Ceramic Alumina) |
Aggressive cleaning and removal of heavy rust, scale, coatings and stubborn contamination |
| Dark Green (Extra-Coarse) |
50 Grit (Ceramic Alumina) |
Heavy cleaning, aggressive deburring, scale removal and coarse surface preparation |
| Yellow (Coarse) |
80 Grit (Ceramic Alumina) |
General cleaning, deburring, oxidation removal and initial surface conditioning |
| White (Medium) |
120 Grit (Ceramic Alumina) |
Light deburring, weld-discolouration clean-up and controlled blending |
| Red (Standard) |
220 Grit (Ceramic Alumina) |
Surface blending, scratch refinement and preparation for finer finishing stages |
| Blue (Fine) |
400 Grit (Ceramic Alumina) |
Fine finishing, satin refinement and smoothing an existing surface pattern |
Availability note: The variation selector shows the current availability for each grade. Some grades may be supplied to order.
For bulk orders, production requirements or confirmed lead times, please contact us to discuss availability.
Operating & Safety Guidance
- Recommended operating speed: 1,500–4,000 RPM
- Maximum permitted speed: 6,000 RPM
- Never exceed the lowest maximum speed stated for the disc, adapter or machine
- Type C bristles are single-directional; install every disc in the correct and consistent direction of rotation
- Use the bristle tips with light, controlled pressure rather than forcing the wheel into the workpiece
- Allow the bristles to follow the workpiece geometry without excessive side loading
- Keep the workpiece moving to limit localised heat and uneven wear
- Check the flange, adapter and shaft fit before starting the machine
- Use suitable machine guarding and personal protective equipment
- Follow the applicable 3M product instructions and workplace safety requirements
Product Specifications
| Product range | 3M Scotch-Brite BB-ZB |
|---|---|
| Legacy Moleroda name | Habras radial disc |
| Nominal diameter | 6″ (approximately 150mm) |
| Bristle type | Type C curved bristles (TC equivalent) |
| Bristle characteristics | Thin, flexible and single-directional |
| Abrasive | Ceramic alumina |
| Available grades | 36, 50, 80, 120, 220 and 400 grit |
| Supply format | Single loose disc |
| Centre hole | 2″ (approximately 51mm) |
| Working wheel | Six to eight matching loose discs |
| Mounting | Compatible flange and adapter system required; not included |
| Recommended speed | 1,500–4,000 RPM |
| Maximum speed | 6,000 RPM |
| Suitable equipment | Bench motors, polishing lathes and compatible low-speed finishing machines |
| Polishing compound required | No |
| Unit of sale | Per individual loose disc |
Complete Your Radial Finishing Setup
Mounting Loose 6-inch Discs
Select the flange and adapter configuration that matches your machine when building a working wheel from loose 3M Type C discs.
Mandrels for Radial Discs
Large Radial Disc Flange & Adapter Mounting System – For 6″ (150mm) Loose Discs
Compare the Dedeco TC Alternative
Dedeco Sunburst TC uses the equivalent curved-bristle construction and is available as either individual loose discs or complete eight-lap wheel assemblies.
