Balanced Aluminium Oxide for Controlled Blasting
Pink fused alumina is engineered to deliver controlled cutting with enhanced durability. The addition of chromium oxide improves toughness while retaining the sharp grain structure associated with white alumina.
Suitable for ferrous and non-ferrous materials in wet or dry blasting systems.
Pink fused alumina is selected where process stability and abrasive longevity are required without sacrificing cutting performance.
Key Features
-
Chromium-modified aluminium oxide grains
-
Sharp, angular cutting action
-
Improved toughness over white alumina
-
Longer service life and controlled breakdown
-
Suitable for ferrous and non-ferrous substrates
-
Compatible with wet and dry blasting systems
Typical Applications
-
Mixed-material blasting operations
-
Precision engineering components
-
Applications requiring controlled surface preparation
-
Environments with varying material hardness
Its balanced grain structure provides consistent results across a wide range of substrates.
Why Choose Pink vs White or Brown Alumina
-
Balanced cutting performance and durability
-
More robust than white alumina
-
Sharper cutting action than brown alumina
Pink fused alumina offers a middle ground between purity and toughness.
It is the preferred choice where both cutting efficiency and abrasive life are important, without committing to the extremes of white or brown alumina.
Technical Information – Pink Fused Alumina
Technical Properties
| Property | Typical Value |
|---|---|
| Chemical composition | Aluminium Oxide with Cr₂O₃ |
| Hardness | Approx. 9.0 Mohs |
| Specific gravity | ~3.9–4.0 g/cm³ |
| Bulk density | ~1.3–2.0 g/cm³ |
| Melting point | ~2050°C |
| Grain shape | Angular |
| Relative toughness | High |
| Contamination risk | Very low |
| Suitable systems | Wet & dry blast cabinets |
Compatible with pressure, suction, and cabinet blasting systems.
Chemical Analysis
| Component | Typical % |
|---|---|
| Al₂O₃ | 99.3% |
| Cr₂O₃ | 0.3% |
| Na₂O | 0.3% |
| Fe₂O₃ | 0.05% |
| CaO | 0.05% |
Approvals & Standards
-
Suitable for industrial and precision blasting environments
-
FEPA F & FEPA P grit standards
-
Used across aerospace, defence, and engineering sectors
Certificates of conformity available on request.
Grades & Supply
-
FEPA macro and micro grades
-
Supplied in 25 kg bags
-
UK stock, 3–5 working day delivery
FEPA grit sizes define the particle size distribution of fused alumina abrasives. Lower FEPA numbers correspond to coarser grains and more aggressive cutting, while higher FEPA numbers produce finer surface finishes and reduced material removal.
FEPA Grit Sizes & Approximate Particle Diameter
| FEPA Grade | Approx. Particle Size (µm) |
|---|---|
| F 008 | 2000 – 2800 |
| F 010 | 1700 – 2360 |
| F 012 | 1400 – 2000 |
| F 014 | 1180 – 1700 |
| F 016 | 1000 – 1400 |
| F 020 | 850 – 1180 |
| F 022 | 710 – 1000 |
| F 024 | 600 – 850 |
| F 030 | 500 – 710 |
| F 036 | 425 – 600 |
| F 040 | 355 – 500 |
| F 046 | 300 – 425 |
| F 054 | 250 – 355 |
| F 060 | 212 – 300 |
| F 070 | 180 – 250 |
| F 080 | 150 – 212 |
| F 090 | 125 – 180 |
| F 100 | 106 – 150 |
| F 120 | 90 – 125 |
| F 150 | 63 – 106 |
| F 180 | 53 – 90 |
| F 220 | 45 – 75 |
Coarser FEPA grades are typically used for heavy rust removal and profiling, while finer grades are selected where controlled surface finish or reduced material removal is required.
Unsure which grit size is right for your application? – Contact us
Our technical team can advise on media selection based on substrate, finish, and blasting system.
Safety & Handling
Pink fused alumina is non-toxic, non-hazardous, and free from silica.
No special disposal precautions are required for the material as supplied; users should consider contamination introduced during their own blasting processes.
